-Performance-
Chipset: SiRFstarIII GSC3fLP
Antenna: Integrated patch antenna
Frequency: L1, 1575.42 MHz
Sensitivity: -159 dBm
Channels: 20 Channel all-in-view tracking
Acquisition time in open sky: Cold Start: 35 sec, Hot Start:
1 sec
Reacquisition: 0.1 sec.
Position update: 1Hz
-Accuracy-
Position:Autonomous < 10 meters, SBAS < 5m
Velocity: 0.1 meter/second
Time: 1 microsecond synchronized to GPS time
Datum: WGS-84
-Electrical Power-
Primary power: 3.3-5.5 Vdc, 50mA typical
Battery: 1100mAh Li-Polymer rechargeable/replaceable
battery
Operation Time: 24 hours (typical)
-Protocol-
Standard interface: USB 1.1 through USB dongle
NMEA-0183 (V3.1) standard
Data rate: 4800 bps
NMEA message: GGA, GSA, GSV, and RMC
WAAS/EGNOS: Enabled
-Physical (Receiver with battery dock)-
Dimension: 2.82in (L) x 1.89in (W) x 0.89in (H)
Weight: 0.15lb (2.3 ounce)
-Environmental-
Operation temperature: -10°C to 60°C (-14°F to 140°F)
Storage temperature: -20°C to 75°C (-4°F to 167°F)
Dynamics: Altitude < 20 km
Velocity: < 1,800 km/h
Acceleration: < 3g
